Windows

E-mail：sales@crystech.com

Tel：+86-532-88703980

Categories:

CRYSTECH is dedicated to manufacturing high precision windows for solid-state laser systems. We have over 20 years of experience in windows manufacturing, design, and coating. We offer a wide range of windows with different materials and different wavelengthes. CRYSTECH own the top coating expert team and the advanced coating machines in China. Our engineers will help you with customized coating design for the windows if needed.

Download

Product Features Specifications& Coatings Standard Products

·Materials available in the visible to infrared wavelength

·Customizable shape and size

·Diameter：3-500mm

·Clear Aperture：>90%

·Flatness：L/10@633nm

·Surface Quality：10/5

·Parallelism：<10″

·High Damage Threshold

·Provide standard coating or customize according to customer needs

Description

CRYSTECH is dedicated to manufacturing high precision windows for solid-state laser systems.
We have over 20 years of experience in windows manufacturing, design, and coating. We offer a wide range of windows with different materials and different wavelengthes. CRYSTECH own the top coating expert team and the advanced coating machines in China. Our engineers will help you with customized coating design for the windows if needed.

Standard Diameter	12.7，15，20，25.4，30mm
Working wavelength	532~2940nm，106μm，etc.
Material	BK7，Fused Silica，etc.
Coating	Uncoated，AR Coating，etc.
